Fundamentals of Digital Image Processing

1. Digital Images: Data with Spatial Structure

In a broader context, it implies digital processing of any two-dimensional data.

Images are data. At its core, a digital image is simply a two-dimensional array of numbers, representing quantities like light intensity, absorption, or temperature at specific locations (pixels). This numerical representation allows computers to process and manipulate visual information. The field encompasses diverse applications, from satellite imaging and medical scans to industrial inspection and robotics.

Processing pipeline. A typical digital image processing sequence involves several steps. First, an analog image (like a photo) is digitized by sampling and quantization. This digital image is then stored, processed by a computer, and finally converted back to analog for display or recording. This pipeline enables complex manipulations not possible with analog methods.

Diverse applications. Digital image processing is crucial across many fields. It helps track Earth resources from space, analyze medical images for diagnosis, guide radar and sonar systems, automate tasks in manufacturing, and even create visual effects for entertainment. Any domain dealing with two-dimensional data can potentially benefit from these techniques.

2. Mathematical Tools: The Language of Image Processing

In this chapter we define our notation and discuss some mathematical preliminaries that will be useful throughout the book.

Foundation in math. Understanding digital image processing requires a grasp of fundamental mathematical concepts. Linear systems theory describes how images are transformed by filters and imaging devices, while Fourier and Z-transforms are essential for analyzing images in the frequency domain. These tools allow us to model and predict system behavior.

Matrices and vectors. Images are often represented as matrices, and operations on images can be expressed using matrix algebra. Concepts like matrix multiplication, transposition, and special matrix types (Toeplitz, Circulant, Unitary) are vital for understanding algorithms in filtering, transforms, and restoration. Block matrices and Kronecker products simplify the analysis of multi-dimensional operations.

Probability and statistics. Images are frequently treated as realizations of random fields, especially when dealing with noise or developing algorithms for entire classes of images. Concepts from probability theory, such as mean, covariance, spectral density, and estimation theory (like the orthogonality principle), are necessary for modeling image properties and designing optimal filters or compression schemes.

3. Human Vision: Guiding Image Processing Design

Understanding of the visual perception process is important for developing measures of image fidelity, which aid in the design and evaluation of image processing algorithms and imaging systems.

Perception matters. When images are intended for human viewing, understanding how we perceive light, color, and spatial patterns is critical. Visual phenomena like simultaneous contrast and Mach bands demonstrate that our perception of brightness is relative, not absolute, and is influenced by surrounding areas. This sensitivity to contrast is key.

Visual system models. The human visual system can be modeled as a filter, with a specific Modulation Transfer Function (MTF) showing sensitivity peaks at mid-spatial frequencies. Color perception involves three types of cones and can be described using color coordinate systems (like RGB, XYZ, Lab) and color difference measures (like CIE formulas) to quantify perceived color variations.

• Luminance: Physical light intensity
• Brightness: Perceived luminance (context-dependent)
• Contrast: Relative difference in luminance
• Hue: Color type (red, green, blue, etc.)
• Saturation: Color purity (amount of white light mixed in)

Fidelity criteria. Subjective evaluation using rating scales (goodness, impairment) is common, but quantitative measures are needed for algorithm design. While mean square error (MSE) is mathematically convenient, it doesn't always correlate well with perceived quality. Frequency-weighted MSE, incorporating the visual system's MTF, or measures based on visibility functions, offer better approximations of subjective fidelity.

4. Digitization: Sampling and Quantizing Images

The most basic requirement for computer processing of images is that the images be available in digital form, that is, as arrays of finite length binary words.

Converting analog to digital. Digitization involves two main steps: sampling and quantization. Sampling converts a continuous image into a discrete grid of pixels, while quantization converts the continuous range of intensity values at each pixel into a finite set of discrete levels. These steps are essential for computer processing.

Sampling theory. The Nyquist-Shannon sampling theorem dictates the minimum sampling rate required to perfectly reconstruct a bandlimited continuous image from its samples. Sampling below this rate causes aliasing, where high frequencies are misrepresented as lower frequencies, leading to irreversible distortion. Practical systems use anti-aliasing filters before sampling.

• Nyquist Rate: Minimum sampling frequency (twice the bandwidth)
• Aliasing: Distortion from undersampling
• Interpolation: Reconstructing continuous signal from samples

Quantization methods. Quantization introduces error by mapping a range of analog values to a single digital value. The Lloyd-Max quantizer minimizes mean square error for a given number of levels, adapting to the input signal's probability distribution. Uniform quantizers are simpler but less optimal for non-uniform distributions. Visual quantization techniques, like contrast quantization or dithering, aim to minimize perceived distortion (e.g., contouring) even with fewer bits.

5. Transforms: Revealing Hidden Image Properties

Most unitary transforms have a tendency to pack a large fraction of the average energy of the image into a relatively few components of the transform coefficients.

New perspectives. Image transforms represent an image as a linear combination of basis images. Separable unitary transforms (like DFT, DCT, DST, Hadamard) are particularly useful as they can be computed efficiently and preserve image energy. They reveal properties like spatial frequency content and are foundational for many processing techniques.

Energy compaction. A key property of many transforms, especially the Karhunen-Loeve (KL) transform, is energy compaction. They concentrate most of the image's energy into a small number of transform coefficients. This is crucial for data compression, as coefficients with low energy can be discarded or quantized more coarsely with minimal impact on overall image quality.

Decorrelation and optimality. Unitary transforms also tend to decorrelate image data, making the transform coefficients less statistically dependent. The KL transform is statistically optimal in that it achieves maximum energy compaction and perfect decorrelation for a given image ensemble. While not always computationally fast, it serves as a benchmark for evaluating other transforms like the DCT, which offers near-optimal performance for typical image models and has fast algorithms.

6. Stochastic Models: Processing Images as Random Fields

In stochastic representations an image is considered to be a sample function of an array of random variables called a random field.

Images as random fields. Stochastic models treat images not as single entities, but as instances drawn from an ensemble of possible images. This allows for the development of algorithms that are robust for a class of images, characterized by statistical properties like mean and covariance functions. Stationary models assume these properties are constant across the image.

Linear system models. Images can be modeled as the output of linear systems driven by random inputs (like white noise). Autoregressive (AR), Moving Average (MA), and ARMA models describe pixel values based on their neighbors and a random component. These models provide a framework for understanding image structure and designing filters.

• AR: Pixel depends on past outputs and current noise (causal)
• MA: Pixel depends on current and past noise (finite impulse response)
• ARMA: Combination of AR and MA

Causal, semicausal, noncausal. These terms describe the dependency structure of the models based on a hypothetical scanning order. Causal models depend only on "past" pixels, semicausal on "past" in one direction and "past/future" in another, and noncausal on "past/future" in all directions. These structures influence the design of recursive, semirecursive, or nonrecursive filtering algorithms.

7. Image Enhancement: Improving Visual Appearance

Image enhancement refers to accentuation, or sharpening, of image features such as edges, boundaries, or contrast to make a graphic display more useful for display and analysis.

Making images look better. Enhancement techniques aim to improve the visual quality of an image for human interpretation or subsequent analysis. Unlike restoration, enhancement is often subjective and application-dependent, focusing on accentuating specific features rather than correcting known degradations.

Point operations. These are zero-memory transformations applied to individual pixel values. Examples include contrast stretching to increase dynamic range, clipping or thresholding to segment specific intensity levels, and digital negatives. Histogram modeling, like histogram equalization, remaps intensity values to achieve a desired distribution, often improving contrast in low-contrast images.

Spatial and transform operations. Spatial operations involve processing pixels based on their local neighborhood. Examples include spatial averaging for noise smoothing, median filtering for impulse noise removal while preserving edges, and unsharp masking for edge crispening. Transform operations apply point transformations in a transform domain (like Fourier or Cosine), enabling frequency-based filtering (low-pass, high-pass, band-pass) or non-linear operations like root filtering or homomorphic filtering.

8. Image Restoration: Recovering Degraded Images

Image restoration is concerned with filtering the observed image to minimize the effect of degradations.

Fixing image problems. Restoration aims to reverse or minimize known degradations introduced during image acquisition, such as blur (due to motion, misfocus, or atmospheric turbulence) and noise. It differs from enhancement by being more objective and based on models of the degradation process.

Linear models and Wiener filter. Degradations are often modeled as linear systems with additive noise. The Wiener filter is a classic approach that provides the best linear mean square estimate of the original image given the degradation model and the statistical properties (power spectra) of the original image and noise. It balances noise smoothing and deblurring.

• Inverse Filter: Undoes blur, but amplifies noise
• Pseudoinverse Filter: Stabilized inverse filter
• Wiener Filter: Optimal trade-off between deblurring and noise smoothing

Implementation and variations. Wiener filters can be implemented in the frequency domain (via FFT) or spatial domain (recursive filters like Kalman filter). FIR Wiener filters approximate the infinite impulse response for efficiency. Spatially varying filters adapt to local image statistics or spatially varying blurs. Other methods include constrained least squares, maximum entropy (for non-negative solutions), and Bayesian methods for non-linear models.

9. Image Analysis: Extracting Features and Understanding Content

The ultimate aim in a large number of image processing applications... is to extract important features from image data, from which a description, interpretation, or understanding of the scene can be provided by the machine.

Understanding image content. Image analysis goes beyond producing another image; it extracts quantitative information to describe or interpret the scene. This involves feature extraction, segmentation (dividing the image into meaningful regions), and classification (assigning labels to regions or objects).

Feature extraction. Features are characteristics that help distinguish objects or regions.

• Spatial Features: Intensity, histogram moments (mean, variance, entropy), texture measures (concurrence matrix, edge density).
• Transform Features: Energy in specific frequency bands or orientations (e.g., using Fourier or Cosine transforms).
• Edge/Boundary Features: Locations of intensity changes (edge maps), linked edges forming contours (chain codes, B-splines), geometric properties (perimeter, area, moments).

Segmentation techniques. Segmentation partitions an image into constituent parts. Methods include amplitude thresholding, component labeling (for connected regions), boundary-based techniques (tracing edges), region-based approaches (clustering pixels with similar features), and template matching (finding known patterns).

10. Image Reconstruction: Building Images from Shadows

An important problem in image processing is to reconstruct a cross section of an object from several images of its transaxial projections.

From projections to slices. Image reconstruction, particularly in medical CT scanning, aims to create a cross-sectional image of an object from multiple one-dimensional projections (ray-sums) taken at different angles. This is a specific type of inverse problem.

The Radon transform. The Radon transform mathematically describes the relationship between a 2D function (the object slice) and its line integrals (the projections). The inverse Radon transform provides the theoretical basis for reconstructing the object from its complete set of projections.

Reconstruction algorithms. The Projection Theorem is fundamental, stating that the 1D Fourier transform of a projection is a central slice of the 2D Fourier transform of the object. This leads to practical algorithms:

• Convolution Back-Projection: Filters each projection and then back-projects the result.
• Filter Back-Projection: Filters projections in the Fourier domain before back-projection.
• Fourier Reconstruction: Interpolates projection Fourier transforms onto a 2D grid and takes an inverse 2D FFT.

Practical considerations. Digital implementations approximate continuous operations. Filters (like Ram-Lak or Shepp-Logan) are used to compensate for the |ξ| filter's high-frequency amplification. Noise in projections requires specialized filters (stochastic filters). Algebraic methods formulate reconstruction as solving a system of linear equations, useful for non-ideal geometries or incorporating constraints.

11. Image Compression: Managing the Data Deluge

Image data compression is concerned with minimizing the number of bits required to represent an image.

Reducing data size. Image data is often massive, requiring significant storage and transmission bandwidth. Compression techniques aim to reduce the number of bits needed to represent an image, ideally without significant loss of visual information. This is achieved by exploiting redundancy and irrelevancy in the data.

Predictive coding (DPCM). These methods exploit spatial redundancy by predicting the value of a pixel based on its neighbors and encoding only the prediction error. DPCM uses a feedback loop to ensure the decoder can reconstruct the image using the same predicted values. It's simple and efficient for real-time applications, offering significant compression over basic PCM.

• Delta Modulation: Simplest DPCM (1-bit quantization)
• 1D DPCM: Predicts based on pixels in the same scan line
• 2D DPCM: Predicts based on neighbors in multiple dimensions

Transform coding. This approach divides an image into blocks, transforms each block (often using a fast unitary transform like DCT), and quantizes the resulting coefficients. Energy compaction means many coefficients are small and can be coded with fewer bits or discarded. Bit allocation strategies distribute bits among coefficients to minimize distortion for a target rate.

• Zonal Coding: Transmits coefficients in a predefined zone of highest variance.
• Threshold Coding: Transmits coefficients above a certain amplitude threshold.

Other techniques. Hybrid coding combines predictive and transform methods. Adaptive techniques adjust predictor or quantizer parameters based on local image characteristics to improve performance. Vector quantization codes blocks of pixels as single units based on a codebook of representative blocks.
